RF-513
Refractory cement is used as the insulation material in foundry furnaces and forges. Its maximum temperature is 2900 Degree Fahrenheit . You'll need around 86 lbs of material per cubic foot, not counting mixing losses.
Lbs required brushing coat 100 sqft: 20 lbsRecommended water % for trowel: 29%Recommended water % for dipping: 50%Example:50 lbs of dry mortar for toweling x 29% water = 14.5 lbs of waterMix the water and dry mortar for 5 minutes.Place in air tight container overnight (12 hours or more)Open container and mix in more water if needed to get desired consistency. (toweling or dipping)Dry mix to a creamy consistency.
Refractory cement is unlike regular cement in that regular cement has water bound up in the compound. Heating regular cement will cause the water to flash to steam and destroy the structure. Refractory cement allows the water to be driven off during curing and in the initial heating. Refractory cement has elements that trap many microscopic air pockets in the mix that provide a high degree of insulation.
How To Use It: Castable refractory cement can be cast in sheet metal forms to create a furnace body. It is worked just like a light weight concrete or masonry mortar. The manufactures literature specifies that 86 pounds of cement will fill a cubic foot of space. Be sure to get extra cement to allow for losses in mixing and pouring. It's a problem to get into a job and find that you don't have enough. Make up brick shaped forms to use any extra. These bricks make great surfaces for welding or brazing. (IFB brick)
Notes on Refractory Curing: Refractory material has various materials in it to create tiny air pockets after curing. These air pockets are what actually insulates the furnace. Typically the manufacturer creates these pockets by adding vermiculite to the mix. This is can cause the curing to be deceptive, because the vermiculite can trap and hold water, even though the cement has kicked off and cured.
The refractory should be allowed to cure for approximately 24 hours before firing. This is an important time, and the longer you can wait, the better. As with concrete, keep the surface from drying out by covering with wetted cloth or burlap if the weather is hot or dry. Also keep in mind that this material does not set as hard and strong as concrete, due to all the trapped air pockets, different cement, and lack of aggregate.
The initial firing, known as calcining, is critical. During this time the refractory is slowly heated from room temperature to the full operating temperature. This should be done over a long time as well, to allow the steam to escape the refractory. Here's a copy of the Manufacturer's Mixing and Curing Instructions.
After the initial firing the unit is ready for use, or ready to have a secondary coating such as ITC-100 or ceramic fiber blankets applied.
WARNING: Do NOT apply any surface coatings, such as ITC-100 or ceramic fiber blankets until the refractory is fully cured and fired. Sealing the surface has caused steam explosions as the refractory heats!!
**If you are using this to rebuild a forge it is recommended you use the pre-mixed formula as it is stronger.
Click here for the product data sheet.
Item #: RCD
Our Kaowool™ cerablanket from ThermalCeramics is 1" thick 8 pound and comes in 25 foot long x 24 inch wide rolls (50 sqft.) We sell it by the linear foot.
Kaowool™ is often used to insulate high temperature furnaces, kilns and in the building of gas forges. Kaowool is the original asbestos replacement material invented by Babcock and Wilcox. Inswool is a similar competing product.
It has a very low density and high purity. It features a maximum temperature rating of 2400°F (1316°C). The blanket can be cut with a scissors making it possible to cut different shapes. Most of our customers use it to line their forges or furnaces and is often left uncoated. Kaowool™ can be coated with a hard refractory to protect it from physical damage and creating airborne refractory dust. ITC-100 is commonly used but is not 100% resistant to poking with sharp objects. A coating of refractory cement or patching compound such as ITC-200 is recommended in hard use areas followed by a coating of ITC-100. If you are interested in purchasing this coating please contact us.
Click here to download more Kaowool™ product information: http://www.thermalceramics.com/site.asp?siteid=4&pageid=47
Click here to download the MSDS (Material Safety Data Sheet): http://www.piehtoolco.com/productinfo/msdskaowool.pdf
Disclaimer: We are not responsible for any damages to your health in relation to your use of this product. Please follow safe practices when installing and working around Kaowool™.
Item #: KW8
The 67C Series regulators are suitable for liquid or vapor service, the 67C Series high pressure (pounds to pounds) regulators are used on a variety of applications. All types within the Series have a 1/4" FNPT side outlet in which a pressure gauge (J500 Series) can be installed. The compact size of the 67C makes it particularly useful on installations where space is limited.
The regulator design utilizes precise guiding of the valve plug to provide close regulation and high performance.
Note: 67C Series regulators do not have an internal relief valve. These units should not be installed in fixed piping serving 1/2 psig (0.03 bar) appliance systems.
Item #: PTREG
